产品概述

The MAX4122–MAX4129 family of operational amplifiers combines wide bandwidth and excellent DC accuracy with rail-to-rail operation at the inputs and outputs. These devices require only 650µA per amplifier, and operate from either a single supply (+2.7V to +6.5V) or dual supplies (±1.35V to ±3.25V) with a common-mode voltage range that extends 250mV beyond VEE and VCC. They are capable of driving 250Ω loads. The MAX4122/MAX4123/MAX4126/MAX4127/MAX4129 have a 5MHz gain bandwidth product, while the decompensated MAX4124/MAX4125/MAX4128 (stable at closed-looped gains of 10 or greater) have a 25MHz gain bandwidth product. In addition, the MAX4123/MAX4125/MAX4127 feature a shutdown mode in which the outputs are placed in a high-impedance state and the supply current is reduced to only 25µA per amplifier.

With their rail-to-rail input common-mode range and output swing, these amplifiers are ideal for low-voltage single-supply operation. Although the minimum operating voltage is specified at 2.7V, the devices typically operate down to 1.8V. In addition, low offset voltage and high speed make them the ideal signal-conditioning stages for precision, low-voltage, data-acquisition systems. The MAX4122 and MAX4124 come in the space-saving 5-pin SOT23-5 package.

关键特性

以下关键特性由Maxim美信半导体提供：

5-Pin SOT23 Package (MAX4122/4)

+2.7V to +6.5V Single-Supply Operation

Rail-to-Rail Input Common-Mode Voltage Range

Rail-to-Rail Output Voltage Swing

5MHz Gain-Bandwidth Product (MAX4122/3/6/7/9)

25MHz Gain-Bandwidth Product (MAX4124/5/8)

650µA Quiescent Current per Amplifier

25µA Shutdown Function (MAX4123/5/7)

200µV Offset Voltage

No Phase Reversal for Overdriven Inputs

Drive 250Ω Loads

Stable with 500pF Capacitive Loads

Unity-Gain Stable (MAX4122/3/6/7/9)

Stable at Gains > 10V/V (MAX4124/5/8)

热门应用

汽车传感器

基站/无线基础架构

电池供电应用

计算机：台式机、工作站和服务器

计算机：主板

计算机：笔记本电脑

数据采集

工业：过程测量与控制

低功耗、低电压应用

面板表

便携式设备

可编程逻辑控制器(PLC)

信号调理
