MAX4213 - 典型电路框图:
MAX4213典型电路框图
承诺原装正品
专营Maxim美信,真正优化您的供应链
Maxim产品 - MAX4213介绍
MAX4213 - 微型、300MHz、单电源、 满摆幅运算放大器,带有使能端

MAX4213是Maxim美信半导体公司的一款视频芯片产品,MAX4213是微型、300MHz、单电源、 满摆幅运算放大器,带有使能端,本站介绍了MAX4213的封装应用图解、特点和优点、功能等,并给出了与MAX4213相关的Maxim元器件型号供参考。

MAX4213 - 微型、300MHz、单电源、 满摆幅运算放大器,带有使能端 - 视频芯片 - Maxim美信半导体高性能芯片品质 - 美信半导体

产品概述

The MAX4212/MAX4213 single, MAX4216 dual, MAX4218 triple, and MAX4220 quad op amps are unity-gain-stable devices that combine high-speed performance with Rail-to-Rail outputs. The MAX4213/MAX4218 have a disable feature that reduces power- supply current to 400µA and places the outputs into a high-impedance state. These devices operate from a 3.3V to 10V single supply or from ±1.65V to ±5V dual supplies. The common-mode input voltage range extends beyond the negative power-supply rail (ground in single-supply applications).

These devices require only 5.5mA of quiescent supply current while achieving a 300MHz -3dB bandwidth and a 600V/µs slew rate. Input-voltage noise is only 10nV√Hz and input-current noise is only 1.3pA√Hz for either the inverting or noninverting input. These parts are an excellent solution in low-power/low-voltage systems that require wide bandwidth, such as video, communications, and instrumentation. In addition, when disabled, their high-output impedance makes them ideal for multiplexing applications.

The MAX4212 comes in a miniature 5-pin SOT23 package, while the MAX4213/MAX4216 come in 8-pin µMAX® and SO packages. The MAX4218/MAX4220 are available in space-saving 16-pin QSOP and 14-pin SO packages.

关键特性
  • 以下关键特性由Maxim美信半导体提供:
  • High Speed:
  • 300MHz -3dB Bandwidth (MAX4212/MAX4213)
  • 200MHz -3dB Bandwidth (MAX4216/MAX4218/MAX4220)
  • 50MHz 0.1dB Gain Flatness (MAX4212/MAX4213)
  • 600V/µs Slew Rate
  • Single 3.3V/5.0V Operation
  • Rail-to-Rail Outputs
  • Input Common-Mode Range Extends Beyond VEE
  • Low Differential Gain/Phase: 0.02%/0.02°
  • Low Distortion at 5MHz:
  • -78dBc SFDR
  • -75dB Total Harmonic Distortion
  • High-Output Drive: ±100mA
  • 400µA Shutdown Capability (MAX4213/MAX4218)
  • High-Output Impedance in Off State (MAX4213/MAX4218)
  • Space-Saving SOT23, µMAX, or QSOP Packages
  • 热门应用
  • 模数转换器接口
  • 电池供电仪表
  • CCD成像系统
  • 视频线驱动器
  • 视频路由与切换系统
