MAX71020A - Energy Measurement AFE
MAX71020A是Maxim美信半导体公司的一款电能测量与计量SoC产品，MAX71020A是Energy Measurement AFE，本站介绍了MAX71020A的封装应用图解、特点和优点、功能等，并给出了与MAX71020A相关的Maxim元器件型号供参考。
MAX71020A - Energy Measurement AFE - 电能测量与计量SoC - Maxim美信半导体高性能芯片品质 - 美信半导体
产品概述
The MAX71020A is a single-chip analog front-end (AFE)for use in embedded energy measurement applications.It contains the compute engine (CE) found inMaxim Integrated’s fourth-generation meter system-on-chip(SoC) and an improved analog-to-digital converter(ADC). It interfaces to a host controller of choice over aSPI interface.
The MAX71020A comes in a 28-pin TQFN package.
关键特性
以下关键特性由Maxim美信半导体提供：Best-in-Class Embedded Algorithms Support HighlyAccurate Electricity MeasurementsVoltage, Current, and FrequencyActive, Reactive, and Apparent Power/EnergyDigital Temperature Compensation40Hz–70Hz Line Frequency Range and PhaseCompensation (±10°)Advanced AFE with Exceptional Accuracy andTemperature StabilityVoltage Reference Temperature Coefficient:40ppm/°C (max)On-Chip Digital Temperature Sensor24-Bit 2nd Order Delta-Sigma ADCs withDifferential and Single-Ended Inputs±0.1% Wh Accuracy over 2000:1 Current RangeHighly Integrated Features Support Compact DesignCycles and Reduced Bill of MaterialsSmall, 28-Pin TQFN PackageDigital Temperature CompensationLow Power ConsumptionLess Than 5mA (typ) Consumption at 3.3VSimple Host InterfaceSPI SlaveAtomic Measurements OutputsDIO or SPI-Based Status Signals热门应用
null电网适用器件及智能插座null
