MAX9282 - 典型电路框图：
MAX9282典型电路框图
Maxim美信半导体芯片：
承诺原装正品
专营Maxim美信，真正优化您的供应链
Maxim产品 - MAX9282介绍

MAX9282 - 3.12Gbps GMSL Deserializers for Coax or STP Input and LVDS Output

MAX9282是Maxim美信半导体公司的一款电平转换器产品，MAX9282是3.12Gbps GMSL Deserializers for Coax or STP Input and LVDS Output，本站介绍了MAX9282的封装应用图解、特点和优点、功能等，并给出了与MAX9282相关的Maxim元器件型号供参考。

MAX9282 - 3.12Gbps GMSL Deserializers for Coax or STP Input and LVDS Output - 电平转换器 - Deserializers Enable Use of Coax Cables, Reducing Weight and Cost of Cabling in Automotive Infotainment - 美信半导体

产品概述

The MAX9278/MAX9282 gigabit multimedia serial link (GMSL) deserializers receive data from a GMSL serializer over 50Ω coax or 100Ω shielded twisted-pair (STP) cable and output deserialized data on 3 of 4 data-lane LVDS outputs (oLDI).

The MAX9282 has HDCP content protection but otherwise is the same as the MAX9278. The deserializers pair with any GMSL serializer capable of coax output. When programmed for STP input, they are backward compatible with any GMSL serializer.

The audio channel supports L-PCM I2S stereo and up to eight channels of L-PCM in TDM mode. Sample rates of 32kHz to 192kHz are supported with sample depth up to 32 bits.

The embedded control channel operates at 9.6kbps to 1Mbps in UART-to-UART and UART-to-I2C modes, and up to 1Mbps in I2C-to-I2C mode. Using the control channel, a µC can program serializer, deserializer, and peripheral device registers at any time, independent of video timing, and manage HDCP operation (MAX9282). Two GPIO ports are included, allowing display power-up and switching of the backlight among other uses. A continuously sampled GPI input supports touch-screen controller interrupt requests in display applications.

For use with longer cables, the deserializers have a programmable cable equalizer. Programmable spread spectrum is available on the LVDS output. The serial input and LVDS output meet ISO 10605 and IEC 61000-4-2 ESD standards. The core supply is 3.0V to 3.6V and the I/O supply is 1.7V to 3.6V.

The devices are in lead-free, 48-pin, 7mm × 7mm TQFN and QFND packages with exposed pad and 0.5mm lead pitch.
