MAX208E - ±15kV ESD保护、+5V RS-232收发器

MAX208E是Maxim美信半导体公司的一款驱动器-接收器产品，MAX208E是±15kV ESD保护、+5V RS-232收发器，本站介绍了MAX208E的封装应用图解、特点和优点、功能等，并给出了与MAX208E相关的Maxim元器件型号供参考。

MAX208E - ±15kV ESD保护、+5V RS-232收发器 - 驱动器-接收器 - Maxim美信半导体高性能芯片品质 - 美信半导体

产品概述

The MAX202E-MAX213E, MAX232E, and MAX241E are a family of RS-232 and V.28 transceivers with high ±15kV ESD HBM protection and integrated charge pump circuitry for single +5V supply operation. The various combinations of features are outlined in the Selector Guide. The drivers and receivers for all ten devices meet all EIA/TIA-232E and CCITT V.28 specifications at data rates up to 120kbps when loaded.

The MAX211E/MAX213E/MAX241E are available in 28-pin SO and SSOP packages. The MAX202E/MAX232E come in 16-pin TSSOP, narrow SO, wide SO, and DIP packages. The MAX203E comes in a 20-pin DIP/SO package, and needs no external charge-pump capacitors. The MAX205E comes in a 24-pin wide DIP package, and also eliminates external charge-pump capacitors.

关键特性

以下关键特性由Maxim美信半导体提供：

Saves Board Space

Integrated High ±15kV HBM ESD Protection

Integrated Charge Pump Circuitry

Eliminates the Need for a Bipolar ±12V Supply

Enables Single Supply Operation From +5V Supply

Integrated 0.1µF Capacitors (MAX203E, MAX205E)

24 pin SSOP Package Saves up to 40% Versus SO Package

Saves Power for Reduced Power Requirements

1µA Shutdown Mode

15µA Shutdown Mode for MAX213E

热门应用

电池供电设备

手持式装置
